| اسم العلامة التجارية: | Firepower |
| رقم الطراز: | MG2 |
| الـ MOQ: | 1 |
| السعر: | 500$ |
| شروط الدفع: | الاعتماد المستندي، تي/تي |
| القدرة على التوريد: | 500/شهر |
| Parameter | Unit | Test Conditions | MG2 | MG2A | MG2B | MG2C |
|---|---|---|---|---|---|---|
| Measuring range | °/s | ±500 | ±500 | ±500 | ±400 / ±400 / ±300 | |
| Zero-bias instability | °/h | Allan variance | 1 | 1 | 1 | 0.1 / 0.05 / 0.08 |
| Zero bias stability | °/h | 1s smooth, RMS, Normal temperature | 10 | 10 | 10 | 5 / 1 / 3 |
| Zero-bias error at full temperature | °/h | 10s smoothing, RMS Temperature change rate 1 ℃/min | 20 | 20 | 20 | 10 / 2 / 5 |
| Random walk | °/√h | Allan variance | 0.15 | 0.15 | 0.15 | 0.05 / 0.02 / 0.03 |
| Zero-bias repeatability | °/h | Q = 6, normal temperature | 10 | 10 | 10 | 5 / 1 / 5 |
| Zero-bias acceleration sensitivity | °/h/g | Test at ± 1 g | 1 | 1 | 1 | 1 / 1 / 1 |
| Resolution | °/h | 2 | 2 | 2 | 1 / 0.5 / 1 | |
| Output noise | °/s | Peak (Half Peak, RMS *3) | 0.4 | 0.3 | 0.4 | 0.25 / 0.15 / 0.2 |
| Bandwidth | Hz | 250 | 250 | 150 | 400 | |
| Scale factor nonlinearity | ppm | Normal temperature | 300 | 300 | 300 | 300 / 300 / 300 |
| Scale factor repeatability | ppm | Q = 3, normal temperature | 300 | 300 | 300 | 300 / 300 / 300 |
| Cross coupling | % | Normal temperature | 0.2 |
| Parameter | Unit | MG2y |
|---|---|---|
| Voltage | V | 5±0.25 |
| Starting current | mA | 200 |
| Steady-state power consumption | W | ≤1 |
| Ripple | mV | 100 |
| Parameter | Unit | MG2y |
|---|---|---|
| Operating temperature | ℃ | -45~85 |
| Storage temperature | ℃ | -55~105 |
| Parameter | Unit | MG2y |
|---|---|---|
| Weight | g | ≤20 |
| Start time | s | <1 |
